Product

MEMBRANE SHEET

Products MEMBRANE SHEET

  • Description

    MPS® flat membrane is manufactured from Polyethersulfone(PES) and is available in various specifications from 0.2 to 8.0um to meet customer needs. Our membranes, which have various pores, are suitable for use in various processes that manufacture final filtration for IV line filter, syringe filter, diagnostic kit for blood separation. MPS® Flat Membrane is produced in rolls with a thickness of 100um, making it suitable for a variety of applications as well as pleated filter materials.

Features

High flow rates and throughputs due to a symmetric pore structure

Good chemical compatibility

Inherently hydrophilic

Available in a wide range of pore sizes

Low protein binding characteristics

  • MPS01 - downstream

  • MPS01 - upstream

  • MPS01 - 단면

Specifications

Type: MPS02 , MPS12 , MPS30 , MPS50 , MPS80

Pore size: 0.2um , 1.2um , 3um , 5um , 8um

Dimension: Roll type : width 41mm , 254mm , 508mm

Bacterial Removal Test

  • Test Method: ASTM F838-15A

    EFA: 7,500 cm²

    Product Name: MPS Series

    Analytical filter: Millipore S-pak

    Test Venue: Chung Ah Filter Bio Laboratory

Mechanical Properties

Application

Used in GMP pharmaceutical manufacturing processes in general research grades such as infusion filters, syringe filters, syringe filters, and diagnostic kits

  • IV Filter

    IV Filter

  • SVP/LVP

    SVP/LVP

  • Bioprocess

    Bioprocess

  • API

    API

  • Biological

    Biological
